Trikdis WP17 slimme WiFi-controller

The Trikdis WP17 WiFi Gate Remote Control Module allows you to open / close motorized gates, garage doors, barriers, doors with a free smartphone app.

Control Options:

• Free application (with revocable permissions)

Main Features:

• Free Protegus 2 Mobile (Android and iOS, iPhone) and Web application (from any browser)
• Easy, fast installation (no router settings required, no need for Fixed IP or Dynamic DNS due to the Protegus 2 server)
• Event logging (time of opening, closing, user)
• WiFi network connection
• Contacts:
  • 1 customizable relay with 1 A 30 V DC, 0.5 A 125 V AC switching (pull-in) time
  • 4 contacts, which can be selected as input and output (e.g., for a garage, gate and pedestrian gate, or 2-3. barriers, etc.)
• Connection and communication are encrypted (AES-128)

For Installers:

• 3 programming options:
  • locally via USB programming software
  • remotely via programming software
  • remotely from Protegus 2
• User editing in programming software or Protegus 2 application (synchronized)
• 2 access levels for module configuration and control: Administrator, Installer
• RFID reader compatibility (Wiegand)
• RS485 port for other compatible devices
• 990 user names with phone or RFID number and email address (for the Protegus 2 system)
• 5000-entry event log, easy copying (e.g., to Excel)

Thanks to its above scaling, it can be used without compromise not only for a family house, condominium, or office but also for an office building, accommodation facility, or even an industrial site.
